PLC Control Roof / Wall Panel Color Steel Plate Roll Forming Machinery CE Approved
Description:
CE Roof & Wall Panel Color Steel Roll Forming Machine Main parameter
No. | main parameter of Roll Forming Machine | |
1 | Suitable to process | Color steel plate |
2 | Width of the plate | 1250 mm |
3 | Rollers | Up layer:10 rows Down layer:16 rows |
4 | Dimensions | 7.6*1.55*1.71m |
5 | Power | 4+4kw |
6 | Thickness of the plate | 0.3-0.6mm |
7 | Productivity | 8-10m/min |
8 | Material of the cutting blade | Cr12 |
9 | Diameter of the roller | Φ70mm |
10 | Weight | About 5.9T |
11 | Voltage | 380V 50Hz 3phases |
15 | Control system | PLC control |
|
